VIVOTEK
User's Manual - 93
Security > User accounts
This section explains how to enable password protection and create multiple accounts.
Root Password
The administrator account name is “root”, which is permanent and can not be deleted. If you
want to add more accounts in the Manage User column, please apply the password for the “root”
account rst.
1. Type the password identically in both text boxes, then click Save to enable password protection.
2. A window will be prompted for authentication; type the correct user’s name and password in their
respective elds to access the Network Camera.
Privilege Management
PTZ control: You can modify the management privilege for operators or viewers. Select or deselect
the checkboxes, then click Save to enable the settings. If you give Viewers the privilege, Operators
will also have the ability to control the Network Camera through the main page. (Please refer to
Conguration on page 40).
Allow anonymous viewing: If you check this item, any client can access the live stream without
entering a User ID and Password.
Account Management
Administrators can create up to 20 user accounts.
1. Input the new user’s name and password.
2. Select the privilege level for the new user account. Click Add to enable the setting.
Access rights are sorted by user privilege (Administrator, Operator, and Viewer). Only
administrators can access the Configuration page. Although operators cannot access the
Conguration page, they can use the URL Commands to get and set the value of parameters. For
more information, please refer to URL Commands of the Network Camera on page 143. Viewers
can only access the main page for live viewing.
Here you also can change a user’s access rights or delete user accounts.
1. Select an existing account to modify.
2. Make necessary changes and click Update or Delete to enable the setting.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Vivotek IB9371-HT and is the answer not in the manual?

Vivotek IB9371-HT Specifications

General IconGeneral
Built-in HDD-
Flash memory128 MB
Card reader integratedYes
Compatible memory cardsSD, SDHC, SDXC
CertificationCE, LVD, FCC Class A, VCCI, C-Tick, UL
Placement supportedOutdoor
Connectivity technologyWired
Video streamingAdjustable resolution, quality and bitrate Smart Stream II
Total megapixels3 MP
Maximum resolution2048 x 1536 pixels
Video formats supportedH.264, H.265
Image quality adjustmentBrightness, Contrast, Saturation, Sharpness
Video compression formatsH.264, H.265, M-JPEG
Supported graphics resolutions2048 x 1536 (QXGA)
Sensor typeCMOS
Optical sensor size1/2.8 \
Digital zoom48 x
Focal length range3 - 9 mm
Maximum aperture number2.3
Audio input1
Camera shutter speed1/5 - 1/16000 s
Minimum illumination0.001 lx
Form factorBullet
Mounting typeCeiling/wall
Product colorWhite
LED indicatorsPower, Status
Housing materialMetal
Protection featuresVandal proof
International Protection (IP) codeIP66
LED typeIR
Night vision distance30 m
Audio system2-way
Audio formats supportedG.711
Signal-to-Noise Ratio (SNR)60 dB
Browser supportedMozilla Firefox 7~43 (streaming only) Internet Explorer 7/8/9/10/11
Number of users10 user(s)
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.3af, IEEE 802.3at
Ethernet interface typeFast Ethernet
Supported network protocolsIPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, SSL, TLS
InterfaceRJ-45
DC output voltage12
Power source typePoE
Power consumption (max)11 W
Storage temperature (T-T)-20 - 50 °C
Operating temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)0 - 90 %
Windows operating systems supportedWindows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Weight and Dimensions IconWeight and Dimensions
Height293 mm
Weight1182 g
Diameter88 mm
