VIVOTEK
User's Manual - 129
uart 0 ~ (m-1), m
is uart count
1/4 select correspond uart
(capability.nuart>0)
cameraid 0~255 1/4 Camera ID to control external PTZ cameral
isptz 0 ~ 2 1/7 0: disable PTZ commands.
1: enable PTZ commands with PTZ driver.
2: enable PTZ commands with UART tunnel.
disablemdonptz <boolean> 1/4 disable motion detection on PTZ operation
Group: uart (capability.nuart>0) (product dependent)
NAME VALUE SECURITY
(get/set)
DESCRIPTION
ptzdrivers_i<0~19,
127>_name
string[40] 1/4 The name of the PTZ driver
ptzdrivers_i<0~19,
127>_location
string[128] 1/4 The full path of the PTZ driver
update 1 7/4 update the list of built-in external PTZ drivers
enablehttptunnel <boolean> 4/4 Enable HTTP tunnel channel to control UART
Group:uart_i<0~(n-1)> n is uart port count (capability.nuart>0)
NAME VALUE SECURITY
(get/set)
DESCRIPTION
baudrate 110,300,600,120
0,2400,3600,480
0,7200,9600,192
00,38400,57600,
115200
4/4 set baud rate of COM port
databit 5,6,7,8 4/4 data bits in a character frame
paritybit none,
odd,
even
4/4 For error checking
stopbit 1,2 4/4 1
2-1.5 , data bit is 5
2-2
uartmode rs485,
rs232
4/4 rs485 or rs232
customdrvcmd_i<0~9> string[128] 1/4 PTZ command for custom camera.
