VIVOTEK
148 - User's Manual
mdwin <integer> 6/6 Indicate which motion detection windows detect.
This field is required when trigger condition is “md”.
One bit represents one window.
The LSB indicates the 1
st
window.
For example, to detect the 1
st
and 3
rd
windows, set
mdwin as 5.
mdwin0 <integer> 6/6 Indicate which motion detection windows of profile
1 detect.
inter 1~999 6/6 Interval of snapshots in minutes.
This field is used when trigger condition is “seq”.
weekday 0~127 6/6 Indicate which weekday is scheduled.
One bit represents one weekday.
bit0 (LSB) = Saturday
bit1 = Friday
bit2 = Thursday
bit3 = Wednesday
bit4 = Tuesday
bit5 = Monday
bit6 = Sunday
For example, to detect events on Friday and
Sunday, set weekday as 66.
begintime hh:mm 6/6 Begin time of the weekly schedule.
endtime hh:mm 6/6 End time of the weekly schedule.
(00:00 ~ 24:00 sets schedule as always on)
lowlightcondition 0, 1 6/6 0 => Do action at all times
1 => Do action in low-light conditions
action_do_i<0~(ndo-1)
>_enable
0, 1 6/6 Enable or disable trigger digital output.
action_do_i<0~(ndo-1)
>_duration
1~999 6/6 Duration of the digital output trigger in seconds.
action_cf_enable 0. 1 6/6 Enable media write on CF.
action_cf_folder string[128] 6/6 Path to store media.
action_cf_media NULL, 0~4 6/6 Index of the attached media.
action_cf_datefolder <boolean> 6/6 Enable this to create folders by date, time, and
hour automatically.
action_cf_backup <boolean> 6/6 Enable the capability of backing up recorded files to
the SD card when network is lost.
0: Disabled
1: Enabled
