VIVOTEK
User's Manual - 9
0 ~ 60°
50°
The coverage of the IR lights is level to 60º. The horizontal coverage angle is 50º.
4. Attach the alignment sticker to a preferred location. Aim the the sticker at a direction
you prefer. Drill holes on the wall or ceiling to install the plastic anchors. The included
anchors may not be necessary for installation on different materials.
4
