The Social Distancing package comes with the following components:
1. 1 or multiple SC8131 3D counting cameras.
2. 1 PoE switch
3. 1 NVR
* The Ethernet, HDMI cables, and HDMI extenders are user-supplied.
Wide Entrance
Stitching, up to 6
Master Slave
Deployment
:
If the need should arise, multiple counting cameras can be stitched together to cover a
wide entrance. The calculated data is polled from the Master camera.
A facility may have separate entrance and exit.
Entrance
Exit
