Vivotek VC8101 - Page 173

VIVOTEK
User's Manual - 173
commas> 1280x720,
1280x800
CU8171:
192x192,
256x256,
384x384,
512x512,
768x768,
1056x1056,
1536x1536,
1696x1696
videoin_c<0~1>_mode0_
effectivepixel
<WxH> CU8131:
1280x800
CU8171:
1696x1696
0/7 The visible area of full scene in
this video mode.
The unit is pixel.
videoin_c<0~1>_mode0_
outputsize
<WxH> CU8131:
1280x800
CU8171:
1696x1696
0/7 The output size of source, equal
to the captured size by device,
in this video mode.
The unit is pixel.
videoin_c<0~1>_mode0_
binning
0, 1, 3 CU8131: 0
CU8171: 0
0/7 Indicate binning is used or not in
this video mode.
0: No binning
1: 2x2 binning
3: 3x3 binning
videoin_c<0~1>_mode0_
maxframerate
<A list of
positive
integer
separated by
commas>
CU8131:
30,30,30,30,3
0
CU8171:
15,15,15,15,1
5,15,15,15
0/7 Indicate maximum frame rate
available for the corresponding
resolution. Those values are
one-to-one mapping to the
"resolution" parameter in this
video mode.
videoin_c<0~1>_mode0_
maxfps_mpeg4
<A list of
positive
integer
separated by
commas>
- 0/7 Indicate maximum frame rate
with MPEG4 available for the
corresponding resolution. Those
values are one-to-one mapping
to the "resolution" parameter in
this video mode.
videoin_c<0~1>_mode0_
maxfps_mjpeg
<A list of
positive
integer
separated by
CU8131:
30,30,30,30,3
0
CU8171:
0/7 Indicate maximum frame rate
with MJPEG available for the
corresponding resolution. Those
values are one-to-one mapping
