Vivotek VC8101 - Page 174

VIVOTEK
174 - User's Manual
commas> 15,15,15,15,1
5,15,15,15
to the "resolution" parameter in
this video mode.
videoin_c<0~1>_mode0_
maxfps_h264
<A list of
positive
integer
separated by
commas>
CU8131:
30,30,30,30,3
0
CU8171:
15,15,15,15,1
5,15,15,15
0/7 Indicate maximum frame rate
with H.264 available for the
corresponding resolution. Those
values are one-to-one mapping
to the "resolution" parameter in
this video mode.
videoin_c<0~1>_mode0_
description
<string> CU8131:
1-Megapixel
(16:10) (MAX
30fps)
CU8171:
3-Megapixel
Fisheye (MAX
15fps)
0/7 Description about this mode.
fisheyelocaldewarp_c<0~1
>
<boolean> 0 0/7 Indicate whether to support
local dewarp.
videoout_codec <string> - 0/7 Available codec list.
timeshift <boolean> 1 0/7 Indicate whether to support
time shift caching stream.
audio_aec <boolean> 0 0/7 Indicate whether to support
acoustic echo cancellation.
audio_mic <integer> 3 0/7 A 32-bit integer, each bit can be
set separately as follows:
Bit 0 => channel 1 supports
build-in microphone or not.
Bit 1 => channel 2 supports
build-in microphone or not.
The rest may be deduced by
analogy.
audio_extmic <boolean> 0 0/7 Indicate whether to support
external microphone input.
audio_linein <boolean> 0 0/7 Indicate whether to support
external line input.
(It will be replaced by audio_mic
and audio_extmic.)
audio_lineout <boolean> 0 0/7 Indicate whether to support line
output.
