Vizio D50u-D1 Quick Start Guide

TELEVISION ANTENNA CONNECTION PROTECTION
Ground Clamp
Antenna Lead In Wire
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductors
(NEC Section 810-21)
Ground Clamps
Power Service Grounding Electrode System
(NEC ART 250, part H)
Electric Service Equipment
• If an outside antenna/satellite dish or cable system is to be connected to the
TV, make sure that the antenna or cable system is electrically grounded to
provide some protection against voltage surges and static charges.
• Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides
information with regard to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna discharge unit, size of
the grounding conductors, location of antenna discharge unit, connection to
grounding electrodes, and requirements of the grounding electrode.
• Lightning Protection: For added protection of the TV during a lightning storm
or when it is left unattended or unused for long periods of time, unplug the TV
from the wall outlet and disconnect the antenna or cable system.
• Power Lines: Do not locate the antenna near overhead light or power circuits,
or where it could fall into such power lines or circuits. Remember, the screen
of the coaxial cable is intended to be connected to earth in the building
installation.

Vizio D50u-D1 Specifications

General

Screen Type	led
Wall Mount	200mm x 200mm
Tuner	digital
Screen Size	49.5 inches, 50 inches
Refresh Rate	120hz
Motion Enhancement	clear action 240
HDR	no
Built-In Speakers	yes
Surround Sound	dts studio sound
Speakers Output	10 watts
Number Of Speakers	2
HDMI ARC Ports	yes
USB Ports	1
Ethernet	yes
RF Antenna	yes
Bluetooth	no
Network	built-in wi-fi
Headphones Output	no
Digital Optical Audio Outputs	1
Analog Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	1
DVI	0
SmartTV	chromecast
Remote Control	smart
3D	no
Power Consumption	138 kilowatt hours
Depth with Stand	10.04 inches
Height with Stand	28.27 inches
Width with Stand	44.24 inches
Net Weight with Stand	30.86 pounds
Depth without Stand	2.52 inches
Height without Stand	25.91 inches
Net Weight without Stand	30.03 pounds
