Adjusting the Professional Picture Settings
You can manage custom picture modes and adjust professional
picture settings such as HSB, RGB offset, RGB gain, and 11 Point
white balance.
To adjust the professional picture settings:
1. From the PICTURE menu, use
the Arrow buttons to highlight
Professional Picture, and then
press OK. The PROFESSIONAL
PICTURE menu is displayed.
2. Use the Arrow buttons to
highlight the setting you wish
to adjust, then press OK to
change the setting:
• Color Tuner - Adjust the
professional HSB color and
11 point white balance.
• Rename Picture Mode -
Rename a custom picture
mode.
• Create Picture Mode -
Create a custom picture
mode.
• Lock Picture Mode - Lock a
custom picture mode with a
unique passcode.
• Delete Picture Mode - Delete a custom picture mode.
Inputs assigned to that custom picture mode will be set
to Calibrated picture mode.
PROFESSIONAL PICTURE
Color Tuner
Rename Picture Mode
Create Picture Mode
Lock Picture Mode
Delete Picture Mode
Adjusting the Color Tuner Settings
You can adjust the professional HSB color and 11 point white
balance. Test your setting using the SMPTE, Flat, and Ramp test
patterns.
To adjust the color tuner settings:
1. From the PROFESSIONAL PICTURE menu, use the Arrow
buttons to highlight Color Tuner, and then press OK. The
Color Tuner menu is displayed.
2. Use the Arrow buttons on the remote to highlight Hue,
Saturation, Brightness, Offset, or Gain of the color you wish
to adjust. Press the OK button and use the Left/Right Arrow
buttons to adjust the value. When you are finished press the
OK button to save the setting.
3. Use the Arrow buttons to highlight another setting you wish
to adjust.
4. When you are finished adjusting the color tuner settings,
press the EXIT button.
Color Tuner
Red Green Blue Cyan Magenta Yellow
Hue 0 0 0 0 25 -14
Saturation -1 5 -4 0 -2 0
Brightness -24 0 -22 0 0 0
Offset 0 0 0
Gain 0 0 0
