Vizio E40-C2 User Manual

4
33
To turn color channels o and on:
1. From the PICTURE menu, use the Arrow buttons to highlight
Color Calibration and press the OK button. The COLOR
CALIBRATION menu is displayed.
2. Use the Arrow buttons to highlight Color Tuner, and then
press the OK button. The Color Tuner menu is displayed.
3. Use the Arrow buttons on the remote to highlight Red, Green,
or Blue.
4. Press the OK button to turn the color channel o or on. An X
appears over a color channel that has been turned o.
5. Use the Arrow buttons to highlight another color channel to
turn o or on. Only two color channels can be turned o at the
same time.
6. When you are nished with the color channels, press the BACK
button to adjust additional settings or EXIT.
Color Tuner
Red Green Blue Cyan Magenta Yellow
Hue 0 0 0 0 25 -14
Saturation -1 5 -4 0 -2 0
Brightness -24 0 -22 0 0 0
Offset 0 0 0
Gain 0 0 0
To adjust the 11 Point White Balance settings:
1. From the Color Tuner menu, use the Arrow buttons to
highlight Color Tuner, and then press the Left/Right Arrow
buttons until the 11 Point White Balance menu is displayed.
2. Use the Arrow buttons on the remote to highlight the Gain and
Color values you wish to adjust. Press the OK button and use
the Left/Right Arrow buttons to adjust the value. When you
are nished press the OK button to save the setting.
3. When you are nished, press the BACK button to adjust
additional settings or EXIT.
All changes here are saved to Color Temperature.
11 Point White Balance
Gain Red Green Blue
5% 0 0 0

Vizio E40-C2 Specifications

General

Screen Type	led
Wall Mount	200mm x 200mm
Tuner	digital
Screen Size	40 inches
Refresh Rate	120hz
HDR	no
Built-In Speakers	yes
Surround Sound	dts studio sound
Speakers Output	20 watts
USB Ports	1
RF Antenna	yes
Network	built-in wi-fi
Headphones Output	no
Digital Optical Audio Outputs	1
Analog Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	1
DVI	0
SmartTV	vizio internet apps (v.i.a.)
Remote Control	smart
3D	no
Power Consumption	51.9 kilowatt hours
Depth with Stand	8.27 inches
Height with Stand	23.4 inches
Width with Stand	36.06 inches
Net Weight with Stand	16.53 pounds
Depth without Stand	2.6 inches
Height without Stand	21.24 inches
Net Weight without Stand	15.87 pounds
