Page #13 background imageLoading...
Page #13 background image
3
Note: The images shown here are for illustrative purposes only and may be subject to change. The actual on-screen image and text may vary, depending on the model.
3. Use the Arrow buttons on the
remote to highlight Picture Mode,
then use the Left/Right Arrow
buttons to change the picture
mode:
Standard mode sets the
picture settings to the
default settings.
Calibrated mode sets the
picture settings to values
ideal for watching Display in a
brightly-lit room.
Calibrated Dark mode sets the
picture settings to values ideal
for watching Display in a dark
room.
Vivid mode sets the picture
settings to values that produce
a brighter, more vivid picture.
Game mode reduces
throughput delays and
optimizes the picture settings
for displaying game console
output.
Computer mode optimizes the picture settings for displaying
computer output.
ADJUSTING THE PICTURE SETTINGS
Your Display display can be adjusted to suit your preferences and
viewing conditions.
To adjust the picture settings:
1. Press the MENU button on the remote. The on-screen menu is
displayed.
2. Use the Arrow buttons on the remote to highlight Picture and
press OK. The PICTURE menu is displayed.
If you’ve changes to the settings for a picture mode, an
asterisks appears after its name (see
Saving a Custom
Picture Mode
).
4. To manually change each of the picture settings, use the Up/
Down Arrow buttons on the remote to highlight that picture
setting, then use the Left/Right Arrow buttons to adjust the
setting:
Auto Brightness Control - The auto brightness control detects
the light levels in the room and automatically adjusts the
backlight for the best picture. Select O, Low, Medium, or
High.
Backlight - Adjusts the LED brightness to aect the overall
brilliance of the picture. Backlight cannot be adjusted when
starting from some picture modes.
Brightness - Adjusts the black level of the picture. When this
setting is too low, the picture may be too dark to distinguish
details. When this setting is too high, the picture may appear
faded or washed out.
Contrast - Adjusts the white level of the picture. When this
setting is too low, the picture may appear dark. When this
setting is too high, the picture may appear faded or washed
out. If the setting is too high or too low, detail may be dicult to
distinguish in dark or bright areas of the picture.
Color - Adjusts the intensity of the picture colors.
Tint - Adjusts the hue of the picture. This setting is useful in
adjusting the esh tones in the picture. If esh appears too
orange, reduce the level of color before adjusting tint.
Sharpness - Adjusts the edge sharpness of picture elements.
It can be used to sharpen non-HD (high denition) content;
however, it will not produce detail that does not otherwise exist.
5. When you have nished adjusting the picture settings, press
the EXIT button on the remote.
Picture Mode Calibrated
Auto Brightness Control Off
Backlight 90
Brightness 50
Contrast 50
Color 50
Tint 0
Sharpness 20
More Picture
Picture Mode Edit
Color Calibration
Back
Standard picture mode meets Energy Star® requirements.
For the best picture, switch to Calibrated mode. Note
that Calibrated mode does not meet Energy Star®
requirements. Customizing picture settings will change the
energy consumption required to operate the TV.
13

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Vizio E55-E1 and is the answer not in the manual?

Vizio E55-E1 Specifications

General IconGeneral
Screen shapeFlat
Response time- ms
Display diagonal55 \
Display brightness- cd/m²
Display technologyLED
Native aspect ratio16:9
LED backlighting typeFull-Array
Contrast ratio (dynamic)5000000:1
Display refresh rates supported120 Hz
Motion interpolation technology-
Processor cores8
Ambient light sensorYes
Video formats supportedH.265, VP9
Video compression formatsHEVC
Wi-Fi standardsWi-Fi 5 (802.11ac)
HDMI version1.4/2.0
HDMI ports quantity4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in1
On Screen Display (OSD) languagesENG, ESP, FRE
3DNo
Battery typeAAA
Audio decodersDTS Studio Sound, DTS TruVolume
RMS rated power10 W
Number of speakers2
Power consumption (standby)0.5 W
Power consumption (typical)114.18 W
Product colorBlack
Panel mounting interface200 x 200 mm
Remote control typeXRT135 (ED) / XRT132
Package depth195 mm
Package width1382 mm
Package height828 mm
Package weight22389 g
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)254 mm
Width (with stand)1244 mm
Height (with stand)776 mm
Weight (with stand)15798 g
Depth (without stand)78 mm
Height (without stand)716 mm
Weight (without stand)15449 g
