3
Note: The images shown here are for illustrative purposes only and may be subject to change. The actual on-screen image and text may vary, depending on the model.
ADJUSTING THE AUDIO SETTINGS
To adjust the audio settings:
1. Press the MENU button on the
remote. The on-screen menu
is displayed.
2. Use the Arrow buttons on the
remote to highlight Audio and
press OK. The AUDIO menu
is displayed.
3. Use the Arrow buttons to
highlight the setting you wish
to adjust, then press Left/
Right Arrow buttons to change
the setting:
Speakers - Turns the built-in
speakers On or O.
Volume Control Display - Toggle between On or O to hide
or display the on-screen volume slider that appears when
volume is adjusted.
Surround Sound - Surround sound uses DTS TruSurround
to deliver an immersive surround sound experience from
the Display’s internal speakers. TruSurround completes the
entertainment experience by providing deep, rich bass and
by delivering crisp details and clear, intelligible dialog. Select
On or O.
Volume Leveling - Volume leveling uses DTS TruVolume
to
maintain consistent volume levels during transitions between
program content, AV formats, and input sources. Select On or
O. In a few cases, volume leveling may articially suppress
volume increases, making it dicult to hear dialog or attening
sudden noises. If this occurs, turn volume leveling o.
Balance - Adjusts the loudness of the audio output from the
When the Display speakers are set to On, DTS signals
cannot be passed through digital audio outputs.
left and right speakers.
Lip Sync - Adjusts the synchronization between the display
image and the accompanying audio track.
Digital Audio Out - Changes the type of processing for digital
audio out and HDMI ARC output when connected to a home
theater audio system. Select Auto, PCM, Dolby D, or Bitstream.
Analog Audio Out - Sets the volume control properties for
the RCA connector when connected to a home theater audio
system. Select Variable if you are controlling the volume with
the Display’s volume controls, or select Fixed if an external
audio device (sound bar or AV receiver) will control the volume.
Equalizer - Adjusts the boost or attenuation of dierent
frequencies using either preset or custom settings. See
Changing
the Equalizer Settings
.
4. When you have nished adjusting the audio settings, press the
EXIT button on the remote.
You must select Bitstream for audio with more than
two channels (3.0, 5.0, or 5.1, for example).
Changing the Equalizer Settings
The graphic equalizer has several pre-set modes and allows you to
create one custom mode.
To select a pre-set audio mode:
1. Press the MENU button on the remote. The on-screen menu is
displayed.
2. Use the Arrow buttons on the remote to highlight Audio and
press OK. The AUDIO menu is displayed.
3. Use the Arrow buttons to highlight Equalizer and press OK.
The Audio Mode and equalizer settings screen appears.
4. Use the Left and Right Arrow buttons to select an audio mode.
The equalizer bars change to reect the mode.
5. Press the EXIT button on the remote.
To create, modify, or replace the single custom equalizer setting:
1. Press the MENU button on the remote. The on-screen menu is
displayed.
2. Use the Arrow buttons on the remote to highlight Audio and
press OK. The AUDIO menu is displayed.
3. Use the Arrow buttons to highlight Equalizer and press OK.
The Audio Mode and equalizer settings screen appears.
4. Use the Left and Right Arrow buttons to select any audio
mode as a starting point.
5. Use the Arrow buttons to highlight a frequency and then press
OK.
6. Use the Up and Down Arrow buttons to adjust the boost (up)
and attenuation (down) for the frequency.
7. Use the Left and Right Arrow buttons to select another
frequency, if desired, and adjust it.
8. Press the EXIT button on the remote.
Audio
Speakers Auto
Volume Control Display On
Surround Sound Off
Volume Leveling Off
Balance 0
Lip Sync 0
Digital Audio Out Auto
Analog Audio Out Fixed
Equalizer
Back
20
