Vizio PQ65-F1 User Manual

3
19
To show or hide the Flat Test Pattern:
1. From the Color Tuner menu, use the Arrow buttons to
highlight Calibration Tests, and then press the Left/Right
Arrow buttons until the FLAT TEST PATTERN menu is displayed.
Flat Test Pattern
O
2. Use the Arrow buttons on the remote to highlight O. Use the
Left/Right Arrow buttons to select the percentage brightness
for the at test pattern. Selecting a percentage immediately
shows the at pattern at that brightness.
—or—
To disable the Flat Test Pattern, use the Left/Right Arrow
buttons to highlight O.
3. When you are nished, press the Exit button.
To show or hide the Ramp Test Pattern:
1. From the Color Tuner menu, use the Arrow buttons to
highlight Calibration Tests, and then press the Left/Right
Arrow buttons until the RAMP TEST PATTERN menu is
displayed.
2. Use the Arrow buttons on the remote to highlight O. Use the
Left/Right Arrow buttons to select the color for the ramp test
pattern. Selecting a color immediately shows that color ramp.
—or—
To hide the Ramp Test Pattern, use the Left/Right Arrow
buttons to highlight O.
3. When you are nished, press the Exit button.
Ramp Test Pattern
O
To show or hide the SMPTE Test Pattern:
1. From the Color Tuner menu, use the Arrow buttons to
highlight Calibration Tests, and then press the Left/Right
Arrow buttons until the SMPTE TEST PATTERN menu is
displayed.
SMPTE Test Pattern
O
2. Use the Arrow buttons on the remote to highlight O. Use the
Left/Right Arrow buttons to highlight On to show the SMPTE
Pattern.
—or—
To hide the SMPTE Test Pattern, use the Left/Right Arrow
buttons to highlight O.
3. When you are nished, press the Exit button.

Vizio PQ65-F1 Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	65 \
Display brightness	- cd/m²
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	240 Hz
LED backlighting type	Full-Array
Contrast ratio (dynamic)	50000000:1
Display number of colors	1.073 billion colors
Display diagonal (metric)	163.83 cm
Motion interpolation technology	Clear Action 960
3D	No
Network streaming services supported	Vudu
Tuner type	Analog & digital
Video apps	Amazon Prime Video, Netflix
Operating system installed	SmartCast OS
RMS rated power	10 W
Number of speakers	2
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Product color	Black, Silver
Panel mounting interface	400 x 400 mm
HDMI ports quantity	5
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Number of OSD languages	3
On Screen Display (OSD) languages	ENG, ESP, FRE
Power consumption (standby)	0.5 W
Power consumption (typical)	240 W
Package depth	206 mm
Package width	1644.9 mm
Package height	978.9 mm
Package weight	39970 g

Weight and Dimensions

Depth (with stand)	300 mm
Height (with stand)	891.8 mm
Weight (with stand)	24900 g
Depth (without stand)	69.1 mm
Width (without stand)	1446.8 mm
Height (without stand)	831.1 mm
Weight (without stand)	24520 g
