Connecting a device — AUDIO & VIDEO CABLE TYPES
Your TV can be used to display output from most devices.
1. Verify that your device has a video port that matches an available port on the TV (HDMI or Coaxial).
2. Connect the appropriate cable (not included) to the TV and the device.
3. Turn the TV and your device on.
4. Set the TV’s input to match the connection you used (HDMI-1, HDMI-2, etc.).
HDMI
Optical
Standard
RCA
RCA To 3
5mm
HDMI
HDMI CABLE
Coaxial
Optical
Standard
RCA
RCA To 3
5mm
HDMI
COAXIAL CABLE
Connecting a device — AUDIO CABLE TYPES
Your TV can be output sound to an audio device, such as a receiver or soundbar.
1. Verify that your device has an audio port that matches an available port on the TV (HDMI or Optical).
2. Connect the appropriate cable (not included) to the TV and the device.
3. Turn the TV and your device on.
Note: The actual ports and their locations may vary, depending on the TV model.
Optical
Standard
RCA
RCA To 3
5mm
HDMI
OPTICAL/SPDIF CABLE
Optical
HDMI
Optical
Standard
RCA
RCA To 3
5mm
HDMI
HDMI CABLE
