Vizio V585-J01 User Manual

15
3
ADJUSTING THE AUDIO SETTINGS
To adjust the audio settings:
Menu > Audio
Use the Navigation buttons to highlight the setting you wish to adjust, then press
• Digital Audio Out — Select the digital audio output format for both the optical
and HDMI ARC audio devices.
- To hear talk back when Talk Back function is enabled, digital audio out must be
set to PCM.
TIP: You must select Digital for audio with more than two
channels (e.g., 3.0, 5.0, or 5.1).
• Analog Audio Out — Select Variable if you are controlling the volume with the
remote. Select Fixed if an external audio device (sound bar or AV receiver) will
control the volume.
• Dialogue Enhancer — If enabled and the signal source includes Dolby 5.1 AC-4
audio then clarity of dialogue is enhanced.
• eARC — Toggle between ARC (Off) and eARC (On) for audio output using
HDMI 1. If On, audio is sent using eARC and is uncompressed. If Off, audio is
sent using ARC and some audio formats may play in standard Dolby Audio, DTS
Digital Surround, or PCM.
TIP: Your connected sound bar or audio receiver must support
eARC in order to receive uncompressed audio. Check your
device's user manual for more information.
• Equalizer — Only available when Surround Sound is set to OFF. Boosts or
attenuates loudness at different frequencies.
SOUND BAR SETTINGS
If a VIZIO sound bar is detected and connected via CEC (HDMI ARC/eARC), sound
bar settings will appear.
To adjust the sound bar settings:
Menu > Audio > Sound Bar Settings
Use the Navigation buttons to highlight the setting you wish to adjust, then press
Left/Right Navigation buttons to change the setting.
TIP: Available sound bar menu settings will be specific to the type
of VIZIO sound bar connected. See
Adjusting the CEC Settings on
page 25
to enable CEC under the SYSTEM settings.
Left/Right Navigation buttons to change the setting:
• TV Speakers — Built-in speakers
automaticcaly turn off if a sound bar is
discovered. Turn the built-in speakers On or Off.
• Surround Sound — When set to On, enables
surround sound suitable for sports and TV
shows. Virtual:X
™
adds virtualized height
best for movies.
• Volume Leveling — When set On, DTS
TruVolume
™
audio solution levels the speaker
volume.
• Balance — Balance the audio loudness
between the left and right speakers.
• Bass — Increase or decrease the bass level.
• Treble — Increase or decrease the treble level.
• Lip Sync — Synchronize the display image with the audio track.
Audio
TV Speakers Auto
Surround Sound On
Volume Leveling On
Balance
Bass
Treble
Lip Sync
Digital Audio Out Auto
Analog Audio Out Fixed
Dialogue Enhancer Off
eARC On

Vizio V585-J01 Specifications

General

Screen shape	Flat
Response time	10 ms
Display diagonal	58 \
Display brightness	- cd/m²
Display technology	-
Native aspect ratio	16:9
LED backlighting type	Full-Array
Contrast ratio (dynamic)	200000:1
Supported graphics resolutions	3860 x 2160
Display refresh rates supported	60 Hz
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus)
HDMI ports quantity	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
RMS rated power	10 W
Number of speakers	2
Power consumption (typical)	- W
Wi-Fi standards	Wi-Fi 4 (802.11n)
Bluetooth version	5.0
Stand type	Connected stand
Product color	Black
Panel mounting interface	300 x 200 mm
Package type	Box
Package depth	184.9 mm
Package width	1480.1 mm
Package height	866.9 mm
Package weight	21500 g
Cables included	AC
Remote control type	XRT260

Weight and Dimensions

Depth (with stand)	260.1 mm
Width (with stand)	1305.1 mm
Height (with stand)	823.7 mm
Weight (with stand)	14600 g
Depth (without stand)	86.1 mm
Height (without stand)	762.5 mm
Weight (without stand)	14300 g
