Vizio VW22LHDTV10T User Manual

22″LCD TV Vizio VW22LHDTV10T
54
C745 067T 305220 4T 105 RADIAL E-CAPACTOR 22UF 25V
C615 067T 305470 3T
EC 105℃ 47UF M 16V
C645 067T 305471 1T
EC 105℃ 470UF M 6.3V
C646 067T 305471 1T
EC 105℃ 470UF M 6.3V
C245 067T 305471 3T 470UF +-20% 16V
C755 067T215B221 4T
CAP 105℃ 220UF M 25V 8*12
C752 067T215B221 4T
CAP 105℃ 220UF M 25V 8*12
C728 067T215B221 4T
CAP 105℃ 220UF M 25V 8*12
C710 067T215B221 4T
CAP 105℃ 220UF M 25V 8*12
C448 067T215B221 4T
CAP 105℃ 220UF M 25V 8*12
L601 073T 259901 T CHOKE 22UH 10% TSL0808RA-220K1R7
L602 073T 259901 T CHOKE 22UH 10% TSL0808RA-220K1R7
L603 073T 259901 T CHOKE 22UH 10% TSL0808RA-220K1R7
L604 073T 259901 T CHOKE 22UH 10% TSL0808RA-220K1R7
R01 061T0603153 RST CHIPR 15 KOHM +-5% 1/10W
C01 065T0603104 32 CHIP 0.1UF 50V X7R
LED01 081T 14 24 EL CHIP LED BLUE/DARK RED
715T3001 1 IR BOARD PCB
CN01 033T8032 5F HR CONN.1.25PITCH
051G 200 1 OIL FOR DISAPPEAR
Q901 057G 667 21 STP10NK70ZFP
0M1G1730 8120 SCREW
HS1 Q90T6064 5 GP HEATSINK
051G 200 1 OIL FOR DISAPPEAR
HS2 090G6064 1 GP HEAT SINK
D904 093G 60267 SP10100
0M1G1730 8120 SCREW
051G 200 1 OIL FOR DISAPPEAR
090G6273 1 HEAT SINK
D906 093G 60268 YG865C15RSC
0M1G1730 8120 SCREW
IC801 056G 608 10 IC OZ9938GN-B SOIC-16
IC901 056T 379107 IC LD7575A PS SOP-8
Q903 057G 417 4 PMBS3904/PHILIPS-SMT(04)
Q803 057G 759 2 RK7002
Q802 057G 759 2 RK7002
Q805 057T 600517 AO4616 SOIC-8
Q806 057T 600517 AO4616 SOIC-8
R846 061G0603000 RST CHIPR 0 OHM +-5% 1/10W
R849 061G0603000 RST CHIPR 0 OHM +-5% 1/10W
R808 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R807 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R806 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
