VLT FC 300 - Specifications; Power-dependent Specifications

10 Specifications
10.1 Power-dependent Specifications
PK25 PK37 PK55 PK75 P1K1 P1K5 P2K2 P3K0 P3K7
Typical Shaft Output (hp [kW])
0.34
[0.25]
0.5 [0.37]
0.75
[0.55]
1 [0.75] 1.5 [1.1] 2 [1.5] 3 [2.2] 4 [3] 5 [3.7]
Enclosure IP20/IP21 A2 A2 A2 A2 A2 A2 A2 A3 A3
Enclosure IP20 (FC 301 only) A1 A1 A1 A1 A1 A1 - - -
Enclosure IP55, IP66 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A5 A5
Output current
Continuous
(3x200–240 V) [A]
1.8 2.4 3.5 4.6 6.6 7.5 10.6 12.5 16.7
Intermittent
(3x200–240 V) [A]
2.9 3.8 5.6 7.4 10.6 12.0 17.0 20.0 26.7
Continuous
kVA (208 V AC) [kVA]
0.65 0.86 1.26 1.66 2.38 2.70 3.82 4.50 6.00
Max. input current
Continuous
(3x200–240 V) [A]
1.6 2.2 3.2 4.1 5.9 6.8 9.5 11.3 15.0
Intermittent
(3x200–240 V) [A]
2.6 3.5 5.1 6.6 9.4 10.9 15.2 18.1 24.0
Additional specifications
IP20, IP21 max. cable cross-section
5)
(line
power, motor, brake and load sharing)
[mm
2
(AWG)]
2)
4,4,4 (12,12,12)
(min. 0.2 (24))
IP55, IP66 max. cable cross-section
5)
(line
power, motor, brake and load sharing)
[mm
2
(AWG)]
4,4,4 (12,12,12)
Max. cable cross-section
5)
with disconnect
6,4,4 (10,12,12)
Estimated power loss
at rated max. load [W]
4)
21 29 42 54 63 82 116 155 185
Weight, enclosure IP20 (lbs [kg]) 10.36
[4.7]
10.36
[4.7]
10.58
[4.8]
10.58
[4.8]
10.8 [4.9] 10.8 [4.9]
10.8
[4.9]
14.55
[6.6]
14.55
[6.6]
A1 (IP20) 2.7 2.7 2.7 2.7 2.7 2.7 - - -
A5 (IP55, IP66) 13.5 13.5 13.5 13.5 13.5 13.5 13.5 13.5 13.5
Efficiency
4)
0.94 0.94 0.95 0.95 0.96 0.96 0.96 0.96 0.96
0.34–5 hp [0.25–3.7 kW] only available as 160% high overload.
Table 10.1 Line Power Supply 3x200–240 V AC
