P37K P45K P55K P75K
High/Normal Load
1)
HO NO HO NO HO NO HO NO
Typical Shaft Output (hp [kW]) 50 [37] 60 [45] 60 [45] 75 [55] 75 [55] 100 [75] 100 [75] 125 [90]
Enclosure IP21, IP55, IP66 C1 C1 C1 C2 C2
Enclosure IP20 C3 C3 C3 C4 C4
Output current
Continuous (3x525–550 V) [A] 54 65 65 87 87 105 105 137
Intermittent (3x525–550 V) [A] 81 72 98 96 131 116 158 151
Continuous (3x525–600 V) [A] 52 62 62 83 83 100 100 131
Intermittent (3x525–600 V) [A] 78 68 93 91 125 110 150 144
Continuous kVA (550 V AC) [kVA] 51.4 61.9 61.9 82.9 82.9 100.0 100.0 130.5
Continuous kVA (575 V AC) [kVA] 51.8 61.7 61.7 82.7 82.7 99.6 99.6 130.5
Max. input current
Continuous at 550 V [A] 49 59 59 78.9 78.9 95.3 95.3 124.3
Intermittent at 550 V [A] 74 65 89 87 118 105 143 137
Continuous at 575 V [A] 47 56 56 75 75 91 91 119
Intermittent at 575 V [A] 70 62 85 83 113 100 137 131
Additional specifications
IP20 max. cable cross-section
5)
(line power
and motor)
50 (1) 150 (300 MCM)
IP20 max. cable cross-section
5)
(brake and
load sharing)
50 (1) 95 (4/0)
IP21, IP55, IP66 max. cable cross-section
5)
(line power, motor) [mm
2
(AWG)]
2)
50 (1) 150 (300 MCM)
IP21, IP55, IP66 max. cable cross-section
5)
(brake, load sharing) [mm
2
(AWG)]
2)
50 (1) 95 (4/0)
Max. cable size with line power disconnect
[AWG (mm
2
)]
2)
50, 35, 35
(1, 2, 2)
95, 70, 70
(3/0, 2/0, 2/0)
185, 150, 120
(350MCM, 300MCM,
4/0)
Estimated power loss at rated max. load
[W]
4)
850 1100 1400 1500
Weight, enclosure IP20 (lbs [kg]) 77.16 [35] 77.16 [35] 165 [50] 165 [50]
Weight, enclosure IP21, IP55 (lbs [kg]) 99.21 [45] 99.21 [45] 143.3 [65] 143.3 [65]
Efficiency
4)
0.98 0.98 0.98 0.98
Table 10.9 Line Power Supply 3x525–600 V AC (FC 302 only)
