System Specifications
Model: VR70 and VR150 Underhood Air Compressor
Type: rotary screw
Drive System: front end auxiliary drive
Control: electric on/off 12V clutch control
Maximum Air Delivery:
VR70 70 CFM and 175 PSI / 1207 KPA
VR150 150 CFM and 175 PSI / 1207 KPA
Pressure Regulation: mechanical inlet control valve modulates flow
in response to demand
Engine Controls: throttle control to modulate between idle and upper
limit RPM to maintain air requirements
NOTE: Some trucks have onboard computers that must
be programmed by the OEM dealer to permit operation
of the electronic throttle control.
Safety Features:
200 PSI / 1379 KPA relief valve in oil/air tank
temperature safety sensor in compressor
rapid blow-down valve to discharge system pressure on
shutdown (10-15 seconds)
drive disable circuit (DDC)
Lubrication: VMAC certified and approved synthetic oil
Filters:
paper-type replaceable air filter
spin-on type high pressure oil filter
coalescing separator element
