7.Ifthetankhasasmallspringandthimblescreen,thescreencanberemovedbycarefullypushingit
outoftheoilscavengeholefromtheinsideofthetank.
8.Ifthesystemdoesnothaveasmallspring,thescav engescreenwillbe
locatedinsidethetank
coalescingchamberandisretainedbyasmallscrew.
9.Checkthethimblescreenorscavengescreenforcontaminationordamage.Ifcontaminated,cleanas
necessaryandblowoutwithcompressedair.Ifdamaged,replacethethimblescreenorscavenge
screen.



10.InstallnewO‐
rings(includingthesmallO‐ringfortankswiththeinternalscavenges creen)andrear
capseal.
11.ThoroughlycleanthelargespringandthespringplateonVR140systems.Removeanyrustor
contaminants.
12.Installthelargespring(withspringplateon140systems–taperedendawayfrom
thefilter)anda
newcoalescingseparatorelement.Makesurethatthespringisinplace,asitholdsthecoalescing
separatorelementtightagainsttherearcapseal. 


Thelargespringalsoprevents
electrostaticbuildupbygrounding
thecoalescingseparatorelement.
Ifthespringisnotinstalled,an
electricarcmayoccur,whichcould
resultinanexplosion,potential
tankruptureorfire.

Thecoalescingseparatorelement
servicekitmayincludeawave‐type
spring(Figure6.1).Replacethelarge
coilspringwiththewave springand
discardthecoilspring.

13.Installthedischargecapandtorquetheboltstospecifications.
14.Installthelinesonthebackofthetank.
15.
Removethefillerplugfromtheairinletcontrolvalve.

Ifyouusesolventsforcleaning,
thoroughlyrinsethepartswith
hotwatertoremoveallsolvent
residues.
