32
`
VR70 System (muffler not shown)
VR150 System
Check the inside of the tank for any evidence of metal
filings or contamination; if found, flush the tank, hoses
and cooler. Metal filings will damage the compressor.
Pressure
relief valve
Discharge cap
Spring
Thimble screen
Rear cap seal
Coalescing filter
Coalescing filter spring
O-ring
