Channel Handling
Number of output channels
4 mono,
bridgeable per ch. pair
Number of input channels:
Analog 4 (4x XLR)
AES3 4 (2x XLR)
Audio
Output Noise
A-Weighted @ 8 Ω - Analog to Analog / Digital to Analog
< -70.0 dBV
Dynamic Range
A-Weighted @ 8 Ω - Analog to Analog / Digital to Analog
114,3 dB
Damping Factor @ 8 Ω, 20Hz - 500Hz > 5000
Slew Rate (input filter bypassed) > 50 V/µs
Frequency Response ( -3 dB , 1 W @ 8 Ω) 5 Hz - 30 kHz
Crosstalk (1 kHz) -70 dB
THD+N (from 0.1 W to Full Power)
< 0.5%
(typical < 0.01%)
DIM (from 0.1 W to Full Power)
< 0.5%
(typical < 0.01%)
Input Impedance 20 kΩ Balanced
Input Acceptance +27 dBu
DSP
AD converters
24 Bit Tandem™ @ 96 kHz
129 dB Dynamic Range - 0.00056 % THD+N
DA converters
24 Bit Tandem™ @ 192 kHz
121 dB Dynamic Range - 0.00084 % THD+N
Sample rate converter
24 Bit @ 44.1 kHz to 192 kHz
140 dB Dynamic Range - 0.0001 % THD+N
Internal precision 40 bit floating point
Delay 2 s + 100 ms for time alignment
Equalizer
Raised-cosine, custom FIR, parametric IIR:
peaking, hi/lo-shelving, all-pass,
band-pass, band-stop, hi/lo-pass
Crossover
linear phase (FIR), hybrid (FIR-IIR), Butterworth,
Linkwitz-Riley, Bessel: 6 dB/oct to 48 dB/oct (IIR)
Limiters TruePower™, RMS voltage, RMS current, Peak limiter
Damping control Active DampingControl™
Construction
Dimensions 483 mm x 44.5 mm x 495 mm (19.0 in x 1.75 in x 19.5 in)
Weight 15 kg (33.0 lb)
Output Stage
Maximum output power per channel @ 8 Ω 1600 W
Maximum output power per channel @ 4 Ω 3000 W
Maximum output power per channel @ 2.7 Ω 4000 W
Maximum output power per channel @ 2 Ω 5200 W
Maximum output power @ 8 Ω Bridged 6000 W
Maximum output power @ 4 Ω Bridged 10400 W
Peak total output, all channels driven 20000 W
Maximum unclipped output voltage 175 V
peak
Maximum output current 130 A
peak
The power figure is calculated by driving and loading symmetrically all the
channels: uneven loads allow to achieve highest performance.
AC Mains Power
Single-Phase
Nominal Voltage 100 - 240 V @ 50/60Hz
Operating Range 90 - 264 V from DC to 200Hz
Power Factor
1/8 Maximum Output Power @ 4 Ω
> 0.9
Current Draw
1/8 Maximum Output Power @ 4 Ω
18 A
rms
@ 100V
9 A
rms
@ 240V
Suggested circuit breaker C16
Three-Phase
Nominal Voltage**
208Y / 120 - 416Y / 240 V, 3~,
3W+N+PE @ 50/60Hz
200 V~, 3W+PE @ 50/60Hz
Power Factor
1/8 Maximum Output Power @ 4 Ω
> 0.9
Current Drawn from Each Single Phase
1/8 Maximum Output Power @ 4 Ω
6 A
rms
@ 208Y
3 A
rms
@ 416Y
Suggested circuit breaker (per phase) C10
Bi-Phase
Nominal Voltage 200/100 V, 2W+PE @ 50/60Hz
Idle Consumption (all AC MAINS cases) < 100 W
Max Consumption (all AC MAINS cases) < 3500 W
** Note: 208Y/120 V = 208 V phase-to-phase, 120 V phase-to-neutral
Thermal
Operating temperature 0° - 15°C / 32° - 113°F
Cooling
Fan, continuously variable
speed, teperature controlled
Thermal dissipation
Single phase 115V 230V
1/8 Maximum Output Power @ 8 Ω 1127 BTU/h 1058 BTU/h
1/4 Maximum Output Power @ 8 Ω 2124 BTU/h 1639 BTU/h
Appendix B: Specifications
