Infinite V2
Page 3
Reference Manual
Features
Rugged, touring grade chassis. E.I.A. Standard 19" (48.3cm) rack-mountable.
Ultra reliable 'Super G' class output stage provides maximum stability even into 2 ohm loads.
High efficiency triple rail voltage supply system.
'VSP' Velocity Sense Protection circuitry protects speakers from over excursion.
'CEP' Clip Elimination Protection prevents clipped waveforms from reaching the outputs.
Independent crossover networks with adjustable frequencies and outputs for both channels.
LED display for monitoring the average mains current draw.
Stereo, parallel and bridge operation for optimal load matching.
Independently selectable 25Hz Hi pass filters for greater woofer protection
Relay control power switch with soft start for loudspeaker protection.
Complete protection against shorted outputs, mismatched loads, overheating and DC input/output.
Three year warranty and guarantee.
Precautions
Although your amplifier is protected from external faults, the following safety precautions are recommended:
1. Do not change the position of the bridge mode switch, parallel switch or 25Hz Hi pass filters until
the input levels have been turned down.
2. There are important differences between Stereo, Parallel and Bridge mode operation. Please refer to page
8 for a detailed description of the different modes and there uses.
3. Switch off the amplifier or turn down the inputs before connecting to the in/out XLR's.
4. Do not short the ground lead of an output cable to the input signal ground. This will form a ground loop
and may cause oscillations.
5. Do not connect both channels positive outputs together in parallel or stereo modes. And never connect any
channels positive output to chassis ground.
6. When using the amplifer with 2 ohm loads the 16 Amp CEE Form connector must be replaced with a 32
AMP CEE Form connector.
7. Do not operate the amplifier from AC mains in excess of 10% variation above or below the selected line
voltage, and only at the specified line frequency.
