Linea
3A.9 MOUNTING ON A COMBUSTIBLE SURFACE
If the appliance is to be fitted on a wall of com-
bustible material, a sheet of fireproof material
must protect the wall.
3A.10 TIMBER FRAMED BUILDINGS
If the appliance is to be fitted in a timber framed
building, it should be fitted in accordance with I.S.
813 and local Building Regulations.
The Institute of Gas Engineers publication (IGE/
UP/7) ‘Guide for Gas Installations in Timber
Frame Buildings’ gives specific advice on this type
of installation.
3A.11 INHIBITORS
Vokera recommend that a inhibitor – suitable for
use with low water-content, copper heat exchang-
ers – is used to protect the boiler and system
from the effects of corrosion and/or electrolytic
action. The inhibitor must be administered in strict
accordance with the manufacturers* instructions.
*Fernox and Sentinel manufacture products that
have proved suitable for use with Vokera appli-
ances. Vokera Ltd. cannot comment on the suit-
ability of any other such product with our appli-
ances.
3A.12 DECLARATION OF CONFORMITY
A Declaration of Conformity (as defined in I.S.
813) must be provided on completion of the in-
stallation
A copy of the declaration must be given to the
responsible person and also to the gas supplier
if required.
SECTION 4 INSTALLATION
4.1 DELIVERY
Due to the weight of the appliance it may be nec-
essary for two people to lift and attach the appli-
ance to its mounting. The appliance is contained
within a heavy-duty cardboard carton. Lay the
carton on the floor with the writing the correct way
up.
4.2 CONTENTS
Contained within the carton is:
●●
●●
● The boiler
●●
●●
● The fixing jig and wall bracket
●●
●●
● Template
●●
●●
● An accessories pack containing appliance serv-
ice connections and washers
●●
●●
● The instruction pack containing the installation
& servicing instructions, user instructions,
Benchmark logbook, guarantee registration
card, and a 3-amp fuse
4.3 UNPACKING (fig. 6A)
At the top of the carton pull both sides open – do
not use a knife – unfold the rest of the carton
from around the appliance, carefully remove all
protective packaging from the appliance, and lay
the accessories etc. to one side. Protective
gloves should be used to lift the appliance, the
appliance back-frame should be used for lifting
points.
4.4 PREPARATION FOR MOUNTING THE APPLI-
ANCE
The appliance should be mounted on a smooth,
vertical, non-combustible surface, which must be
capable of supporting the full weight of the appli-
ance. Care should be exercised when determin-
ing the position of the appliance with respect to
hidden obstructions such as pipes, cables, etc.
When the position of the appliance has been
decided – using the template supplied – care-
fully mark the position of the combined fixing jig
and wall- mounting bracket (see fig. 6) and flue-
hole (if applicable).
4.5 FITTING THE FLUE
The top flue outlet permits both horizontal and
vertical flue applications to be considered, alter-
natively, the Vokera twin flue system can be uti-
lised if longer flue runs are required.
4.5.1 CONCENTRIC HORIZONTAL FLUE
(For concentric vertical flue, see 4.5.2)
(For twin flue applications, see 4.5.3)
The appliance can be used with either the stand-
ard 60/100mm concentric flue system or the op-
tional 80/125mm concentric flue system.
NOTE
These instructions relate only to the standard
60/100mm concentric flue system. For specific
details on the installation of the 80/125mm con-
centric flue system please refer to the instruc-
tions supplied.
The appliance flue outlet elbow can be rotated
through 360° on its vertical axis. In addition the
flue may be extended from the outlet elbow in
the horizontal plane (see 2.9). A reduction must
also be made to the maximum length (see table
below) when additional bends are used.
Fig. 6A
