114
11- FRONT AXLE
MODEL VOLARE W8 and W9
Reinforced prolonged model
Meritor MFS 07
Trademark/Model Vigia I
12- FRONT SUSPENSION
MODEL VOLARE W8 and W9
Type Interconnected parabolic spring and telescopic shock absorber
Amortecedores Double-action
Spring
Width 70 mm
Assembly Height
Right 78 mm
Left 86 mm
10- TRACTION AXLE, CONTINUED
MODEL VOLARE W8 and W9
Coupling Ratio 4,10:1 Opc: 4,56:1 Opc: 4,78:1
Number of teeth
Crown Gear 41 41 43
Pinion Gear 10 9 9
Type of Axle Totally Fluctuating
Terminal ( YOKE) Series 1480
Oil SAE 85W 140 API GL 5 EP
Capacity 9,8 litres
