Engine oil level check procedure:
a) Remove the gage rod (1) and clean it with a clean cloth;
b) Insert back the gage rod until the stop piece. Remove it again and check the
level. The level should be between the MIN and Max marks on the gage rod;
c) If the lubricating oil level is at the minimum mark, add lubricating oil of the same
trademark and viscosity throgh the hole (2);
d) To add lubricating oil, remove the oil-feed cover (2) and with a clean funnel,
add the new lubricating oil until it reaches the mark MAX of the gage rod (never
surpass the MAX mark of the gage rod);
CHANGING OF OIL AND LUBRICATING FILTER IN THE ENGINE
Motor lubricating oil change procedure:
VEHICLE’S REACTION
ATTENTION: If the diagnosis lamp starts glowing, stop the vehicle
immediately because the motor may loose capacity and depending on the
gravity of the problem will switch OFF.
To check which case of the abovementioned relates to your vehicle, STOP
in a safe place, activate the parking brake (do not couple the gear) and then
speed it up 100%. After it, it is possible to check the failure gravity. After it,
turn off the vehicle and keep it turned off during several minutes, then turn
it on. If the failure occurs again, avoid risky surpassings.
All the problems that occur in the motor control and management
system, small or big failures, are recorded in the electronic module and
may be deleted only by means of the diagnosis equipment of the Volare
Representantes.
See the orientation chart on the previous page.
CHECK OF THE LUBRICATING OIL LEVEL IN THE ENGINE
Position: in the engine; to reach open the hood.
Check the level, parking your vehicle on a plane site and preferably after the
engine was inactive during the night. If it is not possible, wait at least from 3 to 5
minutes, with the switched off engine, in order to permit the lubricative oil settle
on the bottom of the carter to avoid a wrong reading.
1
2
