116
17- STEERING SYSTEM
MODELO VOLARE W8 and W9
Model ZF SERVOCOM 8090
Number of turns 5
Oil ATF Tipo A
Capacity 1,7 litres
18- SERVICE BRAKE
MODEL VOLARE W8 and W9
Type Drum / “S CAM” pneumatic
19- PARKING BRAKE
MODEL VOLARE W8 and W9
Type Brake spring 24”
Mode of funcitoning Modulator Valve
Actuation Rear Brake
16- CHASSIS
MODEL VOLARE W8 and W9
DESCRIPTION Standart Executive
Type
Dimensions
7655 x 865 mm 6195 x 865 mm
