01-125

Functional check: ABS hydraulic pump -V64-

Test

step

V.A.G

1598

sockets

Item

tested

Test conditions

- Additional

operations

Specification

Measures for

deviations from

specification

18 - Function of

ABS

hydraulic

pump -

V64-

Ignition switched

off

- Pull hydraulic

pump -V64-

connector T2 off

control module

- Connect Ground to

connector T2/1 and

battery voltage to

connector T2/2 on

hydraulic pump

Hydraulic pump

runs without

malfunction (max.

10 secs.)

- Perform output

Diagnostic Test

Mode (DTM)

Page 01-74 .

- Replace control

module.

Hydraulic pump

does not run

Repair Manual,

Brake System,

Repair Group 45

- Replace

hydraulic unit.

Ст

. 24 из 31ABS, ABS/EDL and ABS/EDL/ASR ITT Mark 20 IE, electrical chec
