Volkswagen Golf GTI TCR SEQ User Manual
Volkswagen Golf GTI TCR SEQ User Manual Page 10
2. DRIVER CONTROL
In this section, it is explained how the driver can handle the different commands and functions of the car
within his range while driving
2.1 Main panel
Notes:
- To start the car, always proceed in this order: Main switch, wait until display has booted (VW logo
disappears), then ignition switch.
- The correct procedure to stop the car is the following:
1. Stop the engine using only the yellow switch (ignition switch/KL-15).
2. Wait at least 60 seconds. If the waiting time is lower, the OBD faults memory is not saved.
3. Switch off the car using the red switch (main switch/KL-30).
- If this procedure is followed correctly the OBD faults memory is saved and these faults can be
checked with the diagnostics tools at any time thereafter. These faults are saved until the memory is
deleted manually using the diagnostics program.
The diagnostics tool DiagRA-LE is recommended for customers to be able to check the cars.
Function
Remarks
Ignition switch:
It activates the power to all devices. The Main Switch has to be active.
Main switch:
It activates the power supply.
Lights switch:
It activates the low beam. High beam and flash activation buttons are placed on
the steering wheel module.
Turn indicator:
It activates the left and right turn lights. A green alarm on the display appears
showing that the turn light is blinking.
Brake balance:
Turning the balance wheel you can balance the brake pressure from front to back
or vice versa.
Do not press the brake pedal while moving the balance wheel.
Through the driver display you can check the front and rear brake pressure and the
balance in percentage.
Ignition Switch
Lights Switch
Main Switch
Indicator Switch
Brake balance
