5.10 Airjack
The VW Golf GTI TCR car is provided with an Airjack system. The connector is placed on the rear lateral
right side (inside std refueling cover). The parts are available on the Spare Parts Catalogue.
Airlance inlet threat (LL-03) M16 x 1.5
Notes:
-
IMPORTANT: Never work under a vehicle supported only by Air Jacks unless safety props are fitted.
-
Do not use 'U' bolt type clamps as distortion of the body will cause the Air Jack to stick. Do
not loosen or remove adaptor. Jacks must be vertical during operation. Mounting brackets or
clamps to be fitted to threaded section of body only.
-
Do not use petrol or paraffin for cleaning the Air Jacks as this will damage the rubber seals.
Use an alcohol based cleaning fluid e.g. Methylated Spirit. Use only silicone spray or silicone
grease when internal lubrication is necessary.
