Volkswagen Golf GTI TCR SEQ User Manual Page 32
3.7 Fire extinguisher
All VWMS TCR cars are delivered with an OMP fire extinguisher placed on the boot area. Fulfilling all FIA safety
regulations, the extinguisher can be detonated from the cockpit area using the push button of the control box
placed in the main console or from the outside by a switch on the lowest part of the windscreen.
The extinguisher is equipped with the mandatory anti-torpedo bracket bolted to the chassis.
Notes:
- Check the inner press bottle periodically. It has to be in the green area.
- Check periodically that the 9V inner battery is in good condition
- Do not forget to toggle ON the control box switch before sending the car on the track
