– Pull out door handle -2- towards rear slightly -arrow a- from
support for mounting bracket.
– Swing door handle around in direction of -arrow b-, connection
for interface for entry and start system is guided in mounting
bracket.
– When door handle is perpendicular to door, access and start
authorisation connector is “parked”.
– Pull door handle -1- out to right angle -arrow- in mounting
bracket -1-, the connection -2- for interface for entry and start
system is released at the same time.
2.8.2 Installing
– Place door handle -1- in mounting plate at right angle
-arrow- and engage connection -2- for access and start au‐
thorisation.
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
2. Door components 109
