– Starting in rear area -arrow a-, carefully lift up window slot seal
-1-.
– Pull window slot seal -1- evenly, -arrows b- off door flange
-2-.
4.3.2 Installing window slot seal
– Press window slot seal carefully and evenly, from above, onto
door flange by hand.
4.3.3 Removing front trim
• Window slot trim is removed.
– Pull out window channel -4- from mounting -arrow a-.
– Pull off window channel seal -2- from trim panel -arrow b-.
– Unscrew bolts -3- and pull off trim -1- in direction of B-pillar
-arrow c-.
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
368 Rep. gr.64 - Glazing
