♦ Torque screwdriver - VAS 6494-
Removing
– If fitted, unbolt stone deflector strip.
– Remove heater unit from housing ⇒ page 44 .
– Disconnect electrical connectors -1-.
– Move wiring harnesses aside.
– Unscrew bolts -2-.
– Detach auxiliary air heater control unit - J604- -1- upwards
from heater unit -2-.
Installing
Install in reverse order of removal, observing the following:
Note
When installing, make sure that the 10-pin connection is located
on the glow plug end.
– Screw in bolts -2- loosely.
– Tighten bolts -2- alternately in diagonal sequence to specified
torque.
Specified torques
Component Specified torque
Bolts -2- 1.5 Nm
Transporter 2020 ➤
Auxiliary heater - Edition 04.2020
7. Auxiliary air heater 43
