Operation
- Connect the borescope; start-up of the program “AMCAP” as described under “Initial opera-
tion” and select the driver “Telescope driver” under “Devices”.
- The camera picture is displayed.
- Via the controller “3” the camera brightness can be adjusted.
Main menu bar
File Set Capture File Selection of the memory location for video recordings
(avi). The ending “.avi” must be indicated.
Allocate File Size Set the memory size The available size is displayed.
Under the menu point “Capture File Size” the size can
be entered.
Save Captured Video Saving of a recorded video sequence
Exit Exit the program
Options Preview Real-time display in the main window
Capture Start Capture Start of a video recording. Confirm the displayed stor-
age location with “OK”.
Stop Capture Stops the recording.
Set Frame Rate Set frame rate for the recording (Pictures/sec.)
Set Time Limit Input of a max. recording time in
seconds
Under the main window, the amount of the recorded images is displayed in the status line.
☞
The supplied driver is „TWAIN32 compatible“. Thus, the camera can be operated
with every program that supports this interface.
Snapshot
- In order to save individual pictures, press the key “6” on the borescope. Another window
opens displaying the snapshot image.
- Under the menu point „File“ you can save the picture (Save) or discard and exit (Exit).
- Under the menu point “Rotate orientation” you can rotate the picture.
Magnetic top
The magnetic top can be placed on the camera head. In this way, lost metal parts can be
searched for and found.
Maintenance and Cleaning
The product requires no servicing on your part apart from occasional cleaning. Use a soft, anti-
static and lint-free cloth for cleaning.
Rinse the gooseneck of the borescope carefully with clean water after each application in liq-
uids and dry it before storing it in the case.
Disposal
Electronic products are raw material and do not belong in the household waste.
When the device has become unusable, dispose of it in accordance with the
current statutory regulations at the communal collection points. Disposing of it-
among the household waste is prohibited.
Technical Data
Resolution 640 480 Pixel (VGA)
Frame rate 30 fps (pictures/sec)
Picture 24 Bit RGB Colour (1/6” CMOS)
White comparison automatic
Exposure to light automatic
Video format AVI
Camera illumination 2 LEDs, white
USB port USB 1.1
Power Supply 5V via USB
Ambient/ operating temperature 0 to +45°C
Cable length: approx. 200 cm
Total length of device 88 cm
Effective length of borescope 66 cm
Minimum Bending radius 6 cm
Diameter of camera head 1.4 cm
Lens coverage 54°
Focus > 6cm
Weight without accessories approx. 320 g
Impressum /legal notice in our operating instructions
These operating instructions are a publication by Voltcraft
®
, Lindenweg 15, D-92242 Hirschau/Germany, Phone +49 180/586 582 7 (www.voltcraft.de).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data processing
systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
These operating instructions represent the technical status at the time of printing. Changes in technology and equipment reserved.
© Copyright 2009 by Voltcraft
®
