4. SCOPE OF DELIVERY
• Battery charger
• Mains cable
• Balancer adapter plate with XH connection cable
• Charging cable with open cable ends
• Charging cable with T plug
• Operating Instructions
5. PRODUCT DESCRIPTION
The charger can only be operated at a mains socket (100 - 240 V/AC, 50/60 Hz).
The battery pack to be charged is connected with a charging cable. The enclosed charging
cable has two 4 mm banana plugs on one end and open cable ends on the other. Connection
plugs must be soldered on to the open cable ends matching the rechargeable battery (not
enclosed).
There is an XH adapter plate with connection cable enclosed to connect the balancer connec-
tion of the rechargeable battery to the charger.
The required charging current of 1 A, 2 A, 4 A or 5 A can be set with a slider before charging.
The battery type (LiPo/LiFe) is also selected with by slider.
The charger condition is displayed by a multi-coloured LED. For displaying the individual cells
of the connected battery pack, the balancer display has six individual LEDs.
