VOLTCRAFT VC 870 User Manual

GENERAL SPECIFICATIONS
DISPLAY: 40000 counts MEASURING RATE: Approx. 2-3 measurements / second MEASURING LINE LENGTH: Approx. 90 cm each
MEASURING IMPEDANCE: > 10 MΩ (V range) BAR GRAPH MEASUREMENT RATE: Approx. 10 measurements / second
OPERATING VOLTAGE: 9 V block battery WORKING CONDITIONS: 0 to 30 º C (<75 %RF), 30 to 40 ºC (<50 %RF)
OVER-VOLTAGE CATEGORY: CAT III 1000 V, CAT IV 600 V. contamination degree 2 OPERATING ALTITUDE: max 2000 m
STORAGE TEMPERATURE: -10 to +50 ºC WEIGHT: Approx. 380 g DIMENSIONS (W X H X D): 185 x 91 x 43 mm
TECHNICAL DATA
Functions Range Resolution Accuracy
±(a% reading + b digits)
Overload
protection
Remarks
DCV 400 mV 0.01 mV
±(0.1 % + 5)
1000 V
Impedance: 10 MΩ
4 V 0.1 mV
40 V 1 mV
400 V 0.01 V
1000 V 0.1 V ±(0.2 % + 5)
ACV 4 V 0.001 V
±(1 % + 4)
750 V
Frequency range: 45 - 1000 Hz;
Impedance: 10 MΩ;
TrueRMS in the measuring area of 10 – 100%:
Crest factor: max. 3.0 (at 750V max. 1.5)
40 V 0.01 V
400 V 0.1 V
750 V 1 V ±(1.5 % + 4)
DCA 400 μA 0.01 μA
±(0.5 % + 10)
Fuses
Measurement time limit > 5A: max. 10 s with
10 min break
4 mA
0.1 μA
40 mA
1 μA
400 mA 0.01 mA ±(0.8 % + 10)
10 A 1 A ±(1.5 % + 5)
ACA 400 μA 0.1 μA
±(1.2 % + 4)
750 V
Fuses
Measurement time limit > 5A: max. 10 s with
10 min pause;
Frequency range: 45 - 1000 Hz;
TrueRMS in the measuring area of 10 – 100%:
Crest factor: max. 3.0 (at 750V max. 1.5)
4 mA
1 μA
40 mA 0.01 mA
400 mA 0.1 mA
10 A 0.01 A ±(2.0 % + 3)
Ω
400 Ω 0.01 Ω
±(0.8 % + 10) with REL
function
1000 V
Measurement voltage:
approx. 0.3 V
4 kΩ 0.1 Ω ±(0.5 % + 10)
40 kΩ 0.01 kΩ
±(0.5 % + 3)400 kΩ 0.1 kΩ
4 MΩ 1 kΩ
40 MΩ 0.01 MΩ ±(1.5 % + 5)
PACKAGE CONTENT
Multimeter with spay-cast rubber protection // 9V block battery // Safety measuring cable // Output measuring adapter
// Software CD // Operating instruction
This data sheet is published by Voltcraft®, Lindenweg 15, D-92242 Hirschau / Germany, Phone +49 180 586 582 7. The data sheet reflects the current
technical specifications at time of print. We reserve the right to change the technical or physical specifications.
© Copyright 2010 by Voltcraft®. v1_0710_02-hl
