Data transmission index figures
Baud rate: 9600 Baud
Data bits: 7 bit
Parity: even
Stop bit: 1 bit
Telegram mode C pursuant to to DIN EN 62056-21
Data Telegram Structure
Target / meaning OBIS Comment
Property number 1-0:0.0.0*255 max. 20 characters
Meter state 1-0:1.8.0*255 Meter reading in kWh with 6
pre-decimal and 2 post-deci-
mal digits
L1 – infed power 1-0:2.1.7*255 currently power fed in
on phase 1
L2 – infed power 1-0:4.1.7*255 currently power fed in
on phase 2
L3 – infed power 1-0:6.1.7*255 currently power fed in
on phase 3
L1 + purchased power 1-0:21.7.255*255 currently purchased
power on phase 1
L2 + purchased power 1-0:41.7.255*255 currently purchased
power on phase 2
