Voltech BC-2407HT - Installation Illustration

8
Mode Selection
Remote
Control
Battery Temp.
Sensor
Charger
State
Battery
black (negative)
red (positive)
Remote
Control
Battery Temp.
Sensor
Charger
State
Mode Selection
3
black (negative)
red (positive)
Battery
BC-1230HT / BC-2415HT / BC-1260HT / BC-2430HT
BC-1215HT / BC-2407HT
4. Installation Illustration
Before charging, read the instructions; for indoor use only. Disconnect the supply
before making or breaking the connections to the battery.
