MD2040 with reverse gear MS2L–D
MD2040 with reverse gear MS2L–D
MD2030 with reverse gear MS2A–D
MD2030 with reverse gear MS2A–D
1. Coolant filler cap
2. Expansion tank
3. Relay box with fuses
4. Flexible mounting
5. Starter motor
6. AC generator
7. Dipstick, reverse gear/S-drive
8. Oil filler cap, reverse gear/S-drive
9. Fine fuel filters
10. Oil filler cap, engine
11. Dipstick, engine
12. Air cleaner (ACL)/Air intake
13. Seawater pump
14. Injection pump
15. Lubricating oil filter
16. Fuel pump
17. Oil cooler, reverse gear
18. Folding propeller
19. Cooling water intake, S-drive
20. Sea cock, S-drive
21. Oil drain plug, S-drive
22. Sacrificial anode
6 4 5 4
1 2 3
17 16 15 14 13
7 8 9 11 10 12
6 4 5 4
1 2 3 7 8 12 9 10 11
17 16 15 14 13
