Service and maintenance
Power transmission 135
Drive axles, replacing breather filters
Replace the dive axle breather filters every 2000 hours. The
filter is of the disposable type, i.e. it cannot be cleaned, but
must be replaced.
1 Undo the clamp and remove the filter.
2 Move the clamp over to the new filter and install it.
Take care of filters/oils/liquids in an environmentally safe way,
see page 91.
Full Suspension
checking rubber bearings
Check the rubber bearings for all six FS-cylinders for the first time
at 4000 hours.
Then check every 1000 hours.
If the rubber bearings are worn or heavily cracked, contact a
workshop authorised by Volvo CE for repairs.
NOTE! Neglected checks of the rubber bearings may lead to
damaged cylinders and shortened service life of the machine.
V1052038
Breather filter front axle and dropbox
V1052039
Breather filter, front bogie axle
1031179
Breather filter, rear bogie axle
1035121
A
A Rubber bearings
