Instrument panels
32 Display unit
Operating information
The screen below will be shown when the engine has been
started.
The adjacent screen is shown after pressing the arrow-down key.
Operating information
Time 12-display /24-display Activated exhaust brake
Gear position N/1/2/3/4/5/6/7/8/9/R1/R2/R3 Activated gear-shift inhibitor
Outside
temperature
°C / °F Error code is active
Activated engine braking Next Service
Accumulated values after setting to zero
Number of operated cycles including
dumping after zero setting (To count as one
cycle there has to be an interval of three
minutes between each dumping).
Travelling distance after setting to zero
Operating time after setting to zero Fuel consumption after setting to zero
Current values
Fuel consumption (l/h / gal/h) Gear (N/1/2/3/4/5/6/7/8/9/R1/R2/R3)
Travelling
Speed
km/h/mph Inclination longitudinally (%)
