Volvo B10M - Technical Data

127
Service and Maintenance
Brake cam
Spindle bolt bearing
– top cover x 2
– bottom cover
Belt transmission
– front spider
Propeller shaft
– front spider
– rear spider
Brake cam
Brake cam
Brake cam
Spindle bolt bearing
– top cover x 2
– bottom cover
Steering axle
– upper sliding joint (does not
normally require lubrication but if it
does, the steering wheel must be in
its lowest position first).
– lower sliding joint
Hinge
battery box
