Volvo EC15E - Hammer

Hammer
HB02TLN
Operating weight
(a)
129 kg (284.4 lb)
Breaker weight
(b)
114 kg (251.3 lb)
Overall length 967 mm (38.07 in)
Tool diameter 57 mm (2.24 in)
Flow rate 19–38 l/min (5–10 US gal/min)
Operating pressure 9–12 MPa
Impact rate 450–1000 bpm
a)incl. bracket pins & tool
b)incl. tool but without breaker bracket
Hammer tools
A Moil point
B Pyramid moil
C Chisel parallel
D Chisel transversal
E Blunt
F Spade
GCompacting plate
A B
F
G
V1161653
C D
E
Specifications
Hammer 227
