Lifting objects
The machine can be optionally equipped with
independent or combined systems, allowing the
lifting of various loads as from the excavator
working equipment.
A connecting rod featuring a lifting device across
its structure, in order to proceed the lashing with
appropriate lifting accessories.
A quick coupler featuring a lifting device, in a form
of one or two related eyes , or a lifting hook add-
on either removable or welded.
Always refer to the corresponding manufacturer
user manual delivered with the quick coupler, to
foresee what kind of lifting means are fit for use.
This hardware implies a limitation of the payload
that can be safely lifted by the machine featuring
quick coupler systems, as shown in the decal
15709790.
When using the connecting rod without a quick
coupler, the lifting chart provided at the operator
station shall be used as reference in relation to the
lifting point coordinates, in order to determine the
permissible lifted load.
When using a quick coupler providing a lifting
device, the permissible load of the ensemble is
limited to the lower value of the load chart related
lifting coordinates and the limit value usually
engraved next to the lifting point of the attachment
quick couplert.
The lifted load shall be preferably lashed from the
quick coupler lifting device if available, with lashing
precaution as shown. In this case, it is advisable to
bring up this Safe Working Load information (SWL)
at the operator station as welll.
NOTE!
In the European Community countries, it is
forbidden to proceed load lifting operation, if the
machine is not equipped with due lifting safety
devices on the working equipment and the blade
(optional devices). Always refer to the national
safety-at-work regulation of the machine work site,
to apply additional safety requirements where
necessary.
