Volvo EC20E - Dimensions

Dimensions
V1145832
R
W
L
Q
O
I
J
K
M
S/T X
N
G
H
P
U/V
EC15E, mm (in) EC18E, mm (in) ECR18E, mm (in) EC20E, mm (in)
Dipper arm Short
arm
950
(37.4)
Long
arm
1150
(45.3)
Short
arm
950
(37.4)
Long
arm
1150
(45.3)
Short
arm
950
(37.4)
Long
arm
1150
(45.3)
Short
arm
1050
(41.3)
Long
arm
1350
(53.1)
G Highest
position dozer
blade (short
blade / long
blade)
221 (8.7) / —* 225 (8,86) / 267 (10.51) —* / 259 (10.2)
H Lowest
position dozer
blade (short
blade / long
blade)
267 (10.51) / —* 296 (11.65) / 386 (15.2) —* / 404 (15.91)
I Tumbler
length
1081 (42.56) 1240 (48.82)
J
Track length 1462 (57.56) 1620 (63.78)
Specifications
Dimensions 201
