10. Dozer blade control lever
The control lever controls the position of the dozer
blade.
Lever forward: Dozer blade down.
Lever backward: Dozer blade up.
After pressing the switch for variable tracks
(instrument panel right, read page
38
), the control
lever controls the variable tracks (optional, not for
EC15E),
Lever forward: Extending tracks.
Lever backward: Reduction of tracks width.
11. Throttle lever
Pull the lever back to raise the engine speed.
Push the lever fully forward before shutting down
the engine.
