Information display, operating display
Regarding: L60F, L70F, L90F
Operating display 1
Operating display 1 is shown on the information panel after
machine start. If another display has been set when the machine
was turned off, it is shown instead and change to operating dis‐
play takes place by pressing ESC on the keypad.
The following is shown in the operating display:
- Speed (km/h / mph)
- Selected gear (e.g. F2 = Forward 2) and active gear selector
(F/R / CDC)
- Engine speed (rpm)
- Clock (24 h / am pm)
- Outside temperature (°C / °F)
- Current fuel consumption (l/h) or time remaining for fuel (h).
The lower field may display symbols for various information
according to the following example.
Service mode
Vehicle messages found
Preheating active
Electric lever lock-out 4th function
At speeds above 20 km/h (12 mph) an operating display is shown
regardless if another display figure is selected. If another display
than the operating display is selected, the system will return to
the figure when the speed is below 20 km/h (12 mph).
Change of display is possible only if travel speed is below 20 km/
h (12 mph).
Operating display 2
Operating display 2 is an alternative operating display with less
information. Change to operating display 2 takes place by press‐
ing arrow down.
10 km/h
F2 CDC 800 rpm
11:15 18 °C (64 °F) 10 l/h
10 km/h
11:15 800 rpm
42
