Detach the headlamp connector by
pressing down the clip with your thumb.
At the same time, guide out the connec-
tor with your other hand.
5. Lift out the headlamp and place it on a
soft surface to avoid scratching the lens.
6. Replace the bulb in question.
Securing the headlamp
1. Plug in the connector, a clicking sound
should be heard.
2. Reinstall the headlamp and locking pins.
Check that they are firmly inserted.
3. Check the lighting.
The headlamp must be mounted and the con-
nector firmly connected before the lighting is
switched on or the remote control key is
inserted into the ignition switch.
Related information
•
Lamp replacement - general (p. 362)
•
Lamp replacement - cover for main/
dipped beam bulbs (p. 364)
•
Lamps - specifications (p. 368)
Lamp replacement - cover for main/
dipped beam bulbs
Main/dipped beam bulbs are accessed by
releasing the headlamp's larger cover.
Before starting to replace a bulb, see Lamp
replacement - headlamps (p. 363).
1. Open the lock clamp by pressing up/out.
2. Press down the clips on the cover and
remove it.
Reinstall the cover in reverse order.
Related information
•
Lamp replacement - headlamps (p. 363)
•
Lamp replacement - dipped beam
(p. 365)
•
Lamp replacement - main beam (p. 365)
•
Lamp replacement - extra main beam
(p. 365)
