teries. This is mostly useful for transistor-based fuzz and distortion
circuits, as modern opamp designs are minimally affected by vari-
ations in supply voltage. It is not recommended for digital pedals.
More About Cables
The DC power cables supplied with your Voodoo Lab Pedal Power 2
are suitable for most common pedal effects. If you need additional
cables they are available directly from Digital Music. If you need
cables of a different length, with reversed polarity, or with a special
connector, contact us and we can provide them for you.
Operation
Using the above information, connect the DC power cables between
the Pedal Power outputs and the power jacks on your pedal effects.
Now connect the AC power cord from the AC Power Input jack on
the Pedal Power to a suitable AC outlet. The Pedal Power’s red LED
power indicator should light telling you that it’s working properly.
Frequently Asked Questions
If you have any questions, this is the first place to look!
Why is the LED on my Boss pedal so dim?
Check to see if your Boss pedal is supposed to operate with
an ACA type adapter. It will say this either on a sticker near
the power jack, or on the bottom plate. You need to operate this
pedal at a higher voltage by setting the appropriate Voltage
Selector DIP Switch on the bottom of the Pedal Power to the
“OFF” position. See the section above “Boss Pedals”.
Can the Pedal Power fit in a rack?
The height of the Pedal Power was intentionally kept to 1-3/4
inches so that it can fit in one rack space. When we build
pedal switching racks in (using Digital Music’s Ground
